Learn more by watching our Clipsal 750WPR5-GY | Infrascan Passive Infrared | 18m Detection Range | 3 Wire 240V 10A | Grey video.
The Clipsal 750WPR5-GY is an outdoor passive infrared (PIR) motion sensor rated 240V 10A, with an 18 metre detection range across a 110 degree arc. The 750WPR5-GY switches LED or other lighting loads automatically and carries an IP66 rated housing for exposed outdoor mounting. The sensor is part of the Clipsal Infrascan range and suits residential and commercial installations.
Outdoor sensor lights take a beating from the weather, and cheaper units often fail early as the plastic degrades. The 750WPR5-GY answers that with an IP66 ultrasonically welded housing and UV protected lens and cabling, built for rain, hail and sun. The sensor picks up movement to 18 metres across a 110 degree field, with adjustable sensitivity, lux and time delay.
Licensed electricians reach for the Infrascan because it earns its place over years on the job, not seasons. The 3-wire design drives LED lamps cleanly, suiting upgrades to modern LED floodlights and exterior fittings. Set the sensitivity, lux and time delay trimpots once and the unit keeps switching, with the 5-year Clipsal warranty behind every install.
The 750WPR5-GY is a passive infrared sensor and responds to moving heat, not stationary presence, so it does not hold a light on for a person sitting still. It carries an ambient operating range of 0 to 50 degrees Celsius and switches lighting loads within its 300W LED and 10A rating only, not motors or general power circuits.
Verified Sparky Direct customer reviews: Clipsal Infrascan 750WPR5-GY (750WPR5-GY)
"Been using these for years, I wouldn't use anything else. Always reliable" — Nick
"Easy to install 3 wire movement detector. Range is good. Easy to setup." — Dave
"Solid and reliable. Cheaper sensors often have intermittent issues." — Rhys
(750WPR5-GY)
The 750WPR5-GY runs on 240V mains and must be installed by a licensed electrician. It uses a 3-wire connection (active, neutral, switched active) and surface mounts to a wall or ceiling at a nominal 2.4 metre height. No flush wall box is required.
The 750WPR5-GY carries an IP66 rating, with an ultrasonically welded housing and UV protected lens sealed against dust and heavy water. The cable entry is moisture protected, suiting exposed outdoor walls and eaves. It operates in ambient temperatures from 0 to 50 degrees Celsius.
The Infrascan detects movement up to 18 metres across a 110 degree field. Sensitivity, lux level and time delay are each adjustable by trimpot, so detection distance, the trigger light level, and how long the light stays on can all be set to the site.
The 750WPR5-GY override works from normal automatic mode: flick the wall switch OFF-ON-OFF-ON within 2 seconds to hold the light on for 8 hours. To cancel before the 8 hours end, flick the wall switch OFF-ON within 2 seconds. The sensor returns to automatic detection.
The 750WPR5-GY is backwards compatible with the earlier 750WPR, dropping onto the existing wiring positions for a like-for-like swap. Confirm the existing run is 3-wire before changeover, as the 750WPR5-GY drives LED loads on active, neutral and switched active.
The sensor switches up to 300W of LED load through a 10AX rated relay, sized for outdoor floodlights and exterior fittings. The sealed IP66 housing and UV protected lens resist the moisture and sun that shorten the life of exposed sensors, supporting long outdoor service.
The Clipsal motion sensor carries a 5-year warranty for both domestic and commercial use, handled as an in-home warranty. Warranty runs from the invoice date and requires installation by a licensed electrician. Keep proof of purchase to support any claim.
This passive infrared sensor responds to moving body heat, not stationary presence, so it will not hold a light on for a person sitting still. It switches lighting loads only, within the 300W LED and 10A rating, not power or motor circuits.
The Clipsal 750WPR5-GY is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 5 Year
Commercial Use: 5 Year
Warranty Method: Clipsal in home warranty
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Clipsal by Schneider Electric |
| SKU | 750WPR5-GY |
| Model # | 750WPR5-GY |
| Barcode # | 9311554815530 |
| Package Weight | 0.316kg |
| TYPE | VALUE |
|---|---|
| Type | Sensor |
| Brand | Clipsal by Schneider Electric |
| Range | Infrascan |
| Colour | Grey |
| Device mounting | Surface |
| IP degree of protection | IP 66 |
| [Ue] rated operational voltage | 200...265 V AC |
| [In] rated current | 10 A |
| Movement detection area | 18 m |
| Mounting height | 2.4 m |
