Learn more by watching our Emergency Stop Button 40mm Twist to Release | SB-BOX | XAL-J174H29 video.
The Andeli SB-BOX is an enclosed emergency stop push button station with a red 40mm mushroom head that latches when pressed and releases on a clockwise twist. The station carries one normally closed contact rated 10A at 440V AC, inside a high-impact IP65 enclosure with pre-scored 20mm cable entries. The SB-BOX measures 69 x 69mm at the base and stands 85mm high with the stop button fitted.
Machinery and portable plant often need a stop within reach of the operator, in a position the switchboard cannot cover. Retrofitting one otherwise means sourcing an enclosure, a mushroom actuator and cable entries separately, then assembling them on the bench. The SB-BOX arrives as a complete enclosed station with the 40mm mushroom and N/C contact already fitted. Pre-scored 20mm entries then accept standard conduit or a gland without drilling the housing.
A stop station that mounts straight out of the box saves the assembly time an equivalent parts list would consume. The SB-BOX suits occasional-use stop positions where a station is required but rarely operated, at a price that keeps a small job viable. The twist to release action prevents an accidental reset, because the head stays latched until somebody deliberately turns it. IP65 protection then covers washdown bays and dusty workshops rather than clean panels alone.
Compliance with AS/NZS 4024 or ISO 13850 is not published for the SB-BOX, so it should not be assumed to satisfy a machinery emergency stop function. Where a risk assessment calls for a rated safety component or a monitored contact arrangement, the device for that safety function is determined by the machine designer or a competent engineer. The station carries one normally closed contact and is not rated for immersion, so it suits neither multi-channel safety circuits nor submerged locations.
Verified Sparky Direct customer reviews: Emergency Stop Button 40mm Twist to Release | SB-BOX
"Good entry level stops." — Gary
"This is a sensibly-priced emergency switch from Sparky Direct" — Barrie
(SB-BOX)
No compliance with AS/NZS 4024 or ISO 13850 is published for this station. Whether a device satisfies a machinery emergency stop function is set by the machine's risk assessment, so confirm the requirement with the machine designer or a competent engineer before specifying it.
The mushroom head latches down when pressed and releases when turned clockwise. That prevents a reset by pushing the button a second time, so the stop stays active until somebody deliberately twists the head.
One normally closed contact, rated 10A at 440V AC, which opens when the button latches. A single N/C contact means there is no auxiliary contact and no second channel available for a monitored safety circuit.
The enclosure has pre-scored 20mm entries, so a standard 20mm gland or conduit fitting suits without drilling the housing. Installation is licensed electrical work, and the entry method chosen needs to preserve the IP65 seal.
IP65 covers protection against dust ingress and low-pressure water jets from any direction, which suits wash bays, food areas and dusty workshops. It does not extend to immersion, so submerged or flood-prone locations fall outside the rating.
The enclosure base measures 69 x 69mm and stands 50mm high on its own. With the stop button fitted, overall height is 85mm. Packed weight is 149 grams.
One year for domestic use and one year for commercial use from the invoice date, with the warranty method being return to Sparky Direct. Warranty is void where installation has not been carried out by a licensed electrician.
The Andeli SB-BOX is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
