Stronglink CAT64BL is a Category 6 unshielded twisted pair (UTP) cable designed for high-speed data and communication networks. Supplied in a 305m pull box, this cable features 23 AWG solid bare copper conductors and 4 unscreened twisted pairs, supporting Class E networks up to 250 MHz. It is backwards compatible with Cat 5e systems, making it a versatile choice for both new builds and upgrades.
Designed for durability and ease of installation, the cable includes a blue PVC outer jacket with a 6.2mm diameter and metre marking for quick measurement on-site. Rated for operation between -20°C and 50°C, it meets IEC60332-1 fire safety standards and is RoHS compliant, ensuring safe and reliable performance in a wide range of applications.
Stronglink CAT64BL Features
Where to Use the Stronglink CAT64BL
(CAT64BL)
Yes. Cat 6 UTP supports up to 1Gbps over 100m runs with ease.
Yes. It’s fully backwards compatible, so no problem mixing with Cat 5e systems.
Absolutely. Great for streaming, gaming, and smart home connections.
No. This model is for indoor use. Go for an outdoor-rated or gel-filled cable if you need weather protection.
Yes. It’s built for structured cabling and commercial installs.
Yes. It’s metre-marked and feeds cleanly, saving time during installs.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 1 Year
Commercial Use: 1 Year
Warranty Method: Return to Sparky Direct
| Specification | Details |
|---|---|
| Cable Type | CAT6 Unshielded UTP |
| Cable Colour | Blue |
| Cable Length (Metres) | 305m |
| Termination | Unterminated |
| AWG (Approx) | 24 |
| Conductor Material | Solar-Bare Copper |
| Nom. O.D. | 0.500mm (±0.005) |
| Insulation Material | HDPE |
| Insulation Diameter | 0.88±0.05mm |
| Insulation Thickness | 0.50±0.05mm |
| Sheath External O.D. | 5.3±0.4mm |
| Sheath Surface | Clean, Frap, Satiation |
| Sheath Material | PVC (complies RoHS) |
| Sheath Thickness | 3.0±0.3mm |
| Surface Printing Colour | Black |
| Core Colour | 1 White - Blue/Blue, 3 White - Green/Green, 4 White - Brown/Brown |
| Rip-Cord | Yes |
| Drain Wire | No |
| Before Aging Tensile Strength (Mpa) | ≥13.5 |
| Elongation Before Aging | ≥150% |
| Cold Bend | -20 ±2°C x 4h |
| DC Resistance | 9.5 Ω/100m (max) |
| DC Conductor Resistance Unbalance | 5.0% (max) |
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Stronglink |
| SKU | CAT64BL |
| Model # | CAT64BL |
| Barcode # | 9337376005867 |
| Package Weight | 11.800kg |
| Package Width | 0.340m |
| Package Height | 0.340m |
| Package Length | 0.280m |
| TYPE | VALUE |
|---|---|
| Type | Cat6 |
| Brand | Stronglink |
| Material | PVC |
| Network Category | Cat 6 |
| Sheath | Blue |
| AWG gauge | 23 AWG |
| Length (M) | 305M |
