Learn more by watching our Hager KDN380A | 12 Pole 3 Phase Fork Style Insulated Busbar 80A 16mm video.
The Hager KDN380A is a three-phase insulated busbar rated 80A, carrying twelve connections across a 210mm bar. The KDN380A uses a busbar fork connector and accepts rigid cable at 16mm², with a maximum operating voltage of 400V. The conductor is copper, with moulded stone grey insulation over the body.
Looping individual actives between devices on a three-phase board takes time and puts extra conductors under each terminal screw. The KDN380A carries the phase distribution on one insulated bar, so no looping is required for the active conductors. The fork ends sit over the device terminals and are held by screw or quick connect connection.
Fitting the bar changes the fit-off on a three-phase board: the fork drops onto the terminals and tightens down. The fork busbar installs faster than looping building wire, and twelve connections come off a single part. The bar accepts rigid cable at 16mm² and is rated to 80A.
The Hager KDN380A is a three-phase busbar and is not intended for single-phase distribution. It is not rated above 80A, and its maximum operating voltage is 400V. The cable connection is specified for rigid cable at 16mm², not for a larger cross-section.
Verified Sparky Direct customer reviews: Hager KDN380A | 12 Pole 3 Phase Fork Style Insulated Busbar 80A 16mm² (KDN380A)
"Great product makes wiring a sub board too easy" — Matt
"It Just works, expensive but saves time running individual wires. And safer" — Ned
"Very easy to use." — BC
(KDN380A)
The KDN380A uses a busbar fork connector. The fork ends sit over the device terminals, and the connection is made by screw or quick connect. No looping of active conductors between devices is required along the run.
The KDN380A provides twelve connections across three poles on a 210mm bar. The bar is rated at 80A with a maximum operating voltage of 400V.
The connection cross-section is specified for rigid cable at 16mm². The current-carrying bar is copper, with moulded insulation over the body finished in stone grey.
Sparky Direct stocks the Hager KZ059 fork busbar protective cover and the Hager KZN023 busbar end cap for 2P and 3P bars. Both are sold separately.
The warranty period is one year domestic and one year commercial, starting from the invoice date. The warranty method is return to Sparky Direct. Warranties are void if the product is not installed by a licensed electrician.
The bar is a three-phase busbar with three poles and is not intended for single-phase distribution. It is not rated above 80A, and its maximum operating voltage is 400V.
The Hager KDN380A is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 1 Year
Commercial Use: 1 Year
Warranty Method: Return to Sparky Direct
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Hager Electrical |
| SKU | KDN380A |
| Model # | KDN380A |
| Barcode # | 3250613741006 |
| Package Weight | 0.140kg |
| TYPE | VALUE |
|---|---|
| Type | Insulated Busbar |
| Brand | Hager Electrical |
| Colour | Stone Grey |
| Rated Current (A) | 80 |
| Width (mm) | 210 |
| Number of Poles | 3P |
| Total Number of modules | 12 |
