    Description

    Clipsal 1042TA-WC | Solis T Series 2 Gang Switch 20A/16AX | White Ceramic

    The Clipsal 1042TA-WC Solis T Series 2 Gang Switch in White Ceramic combines functionality with elegant design, making it ideal for homes, businesses, and hotels. This 2-gang toggle switch offers convenient 1-pole 1/2-way control, allowing you to manage two circuits with ease. Crafted from high-quality ceramic, this switch offers durability along with a sleek, sophisticated finish.

    Clipsal Solis T Series Light Switch Features:

    • Dual Circuit Control: 2 Gang toggle switch for managing two circuits with 1-pole 1/2-way control.
    • Premium Finish: Adds elegance and durability to any space.
    • Secure Connections: Screw terminals ensure reliable and safe connections for larger wires.
    • Flush Mounting: Designed for horizontal installation, offering a sleek and modern profile.

    Designed for horizontal flush mounting, this switch provides a streamlined, minimalist look that enhances any modern interior.It is rated for 20A/16AX at 230/240VAC, ensuring reliable and safe operation. The screw terminal design secures connections, reducing the risk of loose wires over time.

    Clipsal 1042TA-WC FAQ:

    Q: What is the rated current and voltage for this switch?
    A: The switch is rated for 20A/16AX at 230/240VAC, 50Hz.

    Q: How many circuits can this switch control?
    A: This 2-gang switch is designed to control two separate circuits.

    Q: What material is used for the construction of this switch?
    A: The switch is made from high-quality ceramic with a polished finish.

    Q: Is this switch suitable for vertical installation?
    A: No, this switch is designed for horizontal installation only.

    (1042TA-WC)

    Warranty

    Warranty starts from Invoice Date

    Domestic Use: 10 Year Mechanical and 7 Year Electrical
    Commercial Use: 10 Year Mechanical and 7 Year Electrical
    Warranty Method: Clipsal in home warranty

    Features
    Specification Details
    Range Clipsal Solis T Series
    Product brand Clipsal
    Product or component type Switch
    Assembly Type Complete product
    Outlet standard deviation Australian/New Zealand
    Colour tint White Ceramic
    Number of gangs 2 gang
    [Ue] rated operational voltage 230/240 V
    Network type AC
    Network frequency 50 Hz
    Rated current 20 A/16 AX
    Control type Toggle switch
    Connections - terminals Screw terminals
    Installation Type Flush
    Number Of Switches 2
    Material Ceramic
    Installation direction Horizontal
    Surface treatment Polished
    Load type LED lamp 0...250 W 20 A/16 AX
    Terminals Capacity 4 x 1.5...3 x 2.5 mm²
    Screwdriver shape Philips No 2
    Square drive no 1 (SQ1)
    Wire stripping length 10 mm
    Mounting Type Screw
    Cover Thickness 3.6 mm
    Mounting Centers 84 mm
    Cut-out dimensions 93 x 50 mm
    Product certifications RCM
    Surface finish Polished
    Height 74 mm
    Width 148 mm
    Depth 56 mm
    Embedding depth 41 mm
    Motor M-rating AS3133 M80
    Switch function 1-pole 1/2-way
    Specifications

    These specifications and characteristics outline physical, mechanical, electrical details.

    Brand Clipsal by Schneider Electric
    SKU 1042TA-WC
    Barcode # 3606487057994
    TYPE VALUE
    Type Switch
    Brand Clipsal
    Range Clipsal Solis T Series
    Colour White Ceramic
    Switch Fucntion 1 Pole 1/2-Way
    Motor M-rating M80 AS3133
    Cut-out Dimensions 93 x 50mm
    Rated Operational Voltage 230/240 V
    Installtion Type Flush
    Assembly Type Complete Product
    Control Type Toggle Switch
    Rated Current 20 A/16 AX
    Height 74mm
    Number of gangs 2
    Width 148mm
    Depth 56mm
    Load type LEDi lamp 0...250 W 20 A/16 AX
    Material Ceramic
