The Clipsal E3045-AW is a five gang light switch rated 10 A 250 V, built on the Clipsal Iconic platform with an Iconic Essence cover frame in Arctic White. The E3045-AW ships complete: switch grid, five rocker mechanisms, pre-installed mounting screws and the Essence cover frame. Each mechanism is a 1-pole 1-way type, so the five rockers switch five separate lighting circuits from one plate. The cover frame is birch timber with an Arctic White face and a birch edge.
By five gangs the plate has become a feature of the wall whether you wanted it to or not, and a flat white one draws the eye for the wrong reason. The E3045-AW puts five rockers on one plate behind a birch timber cover frame, so the switch matches timber cabinetry and door hardware instead of fighting it. The frame is 8.5 mm deep, which keeps the finished face close to the wall. Nothing about the wiring changes.
The E3045-AW terminates and fits off the same way as any other Iconic switch. Mounting screws come pre-installed, so the grid goes straight onto the wall box, and a flap covers the screws and mounting holes once the plate is on. The cover frame uses a clip-on fixing, so the finish can be changed later without disturbing the grid or any of the mechanisms. Each mechanism sits on the standard Iconic grid, so a failed rocker comes out on its own.
The E3045-AW is not weatherproof and carries no IP rating. Keep it out of outdoor and exposed positions, and away from shower and bath splash zones. The timber cover frame is specified for indoor ambient conditions only, so damp or unventilated rooms sit outside its rated humidity range.
(E3045-AW)
The E3045-AW is supplied complete. You get the five gang switch grid with the mounting screws already fitted, five rocker mechanisms, and the Iconic Essence cover frame in Arctic White. It is built from the Clipsal 3045VA-VW complete switch and the E3045C-AW Essence cover frame, so there is nothing else to order.
A licensed electrician has to do the install. It is fixed wiring, so it is electrical work. The switch mounts flush to a standard wall box and the screws are already in the grid, so it fits off like any other Iconic switch once the wiring is landed.
Each rocker is its own 1-pole 1-way mechanism, so all five work independently. That covers five separate lighting circuits at one wall position, such as a bench light, a pendant, a dining light, a pantry light and a hall light. All five mechanisms sit on the one grid.
Yes. The Essence frame is clip-on. It lifts off the grid and any other Iconic 5 gang cover frame clips straight back on, so the finish can change without pulling the mechanisms out or touching the wiring. The grid and all five mechanisms stay in the wall.
It is a flush mount switch and mounts to a standard wall box. The fixing screws come pre-installed in the grid, and a flap covers the screws and mounting holes once the plate is on the wall. A five gang plate is wide, so check the box position and fixing centres on site before you order.
No. It carries no IP rating and is not weatherproof. Keep it out of splash zones, laundries and anywhere outside. It is specified for 0 to 45 degrees C and 10 to 95 per cent humidity. For wet areas, the Iconic IP44 switches are the ones to look at.
One year domestic and one year commercial, starting from the invoice date. Clipsal runs it as an in-home warranty, so Clipsal handles the claim in place rather than you pulling the switch out and sending it back. The warranty is void if the product was not installed by a licensed electrician.
The Clipsal by Schneider Electric E3045-AW is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 1 Year
Commercial Use: 1 Year
Warranty Method: Clipsal in home warranty
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Clipsal by Schneider Electric |
| SKU | E3045-AW |
| Model # | E3045-AW |
| Package Weight | 0.029kg |
| TYPE | VALUE |
|---|---|
| Type | Switches |
| Brand | Clipsal by Schneider Electric |
| Range | Clipsal Iconic Essence |
| Colour | Arctic White |
| Rated Current (A) | 10 |
| Height (mm) | 131 |
| Width (mm) | 85 |
| Complete / Skin Only / Grid Plate Only | Complete |
| Number of Switches / Gangs | 5 |
| Mounting | Flush |
| Voltage (V) | 250 |
| Material | Birch timber cover frame |
| Number of Poles | 1 |
