        Hager KDN380G | 3 Pole 18 Module 80A Insulated Busbar Bar 16mm² | 210mm Length

        The Hager KDN380G is a 3 pole insulated busbar built for reliable phase distribution across modular switchboards and electrical panels. Measuring 210mm, it supports up to 18 modules and connects quickly using 16mm² fork-type terminals.

        With a 415V operational rating and 4000V impulse withstand, this busbar delivers safe, high-performance current distribution in residential or commercial settings. Its 80A current rating makes it suitable for most general power distribution loads.

        KDN380G Features

        • 3 Pole Design: Provides phase distribution for 18 modules
        • 80A Rated Current: Handles standard residential and commercial loads
        • 210mm Length: Sized to support 18 DIN modules
        • 16mm² Conductor Capacity: Fork-type terminals for quick, secure install
        • Voltage Ratings: Ue: 415V | Uimp: 4000V

        KDN380G FAQ

        Q: How many modules does this support?
        A: It supports 18 modules with 3 poles each (total 54 pole connections).

        Q: What conductors is it compatible with?
        A: It accepts rigid copper conductors up to 16mm² using fork terminals.

        Q: Is this suited for standard switchboards?
        A: Yes, it's compatible with modular boards sized for 18 modules.

        (KDN380G)

        Warranty

        Warranty starts from Invoice Date

        Domestic Use: 1 Year
        Commercial Use: 1 Year
        Warranty Method: Return to Sparky Direct

        Specifications

        These specifications and characteristics outline physical, mechanical, electrical details.

        Brand Hager Electrical
        SKU KDN380G
        Model # KDN380G
        TYPE VALUE
        Type Insulated Busbar
        Brand Hager
        Rated Current (A) 80A
        Length (mm) 210mm
        Number of Poles 3
        Connector Type Fork
        Cross-Sec­tion Rigid Conductor 16mm²
