    Description

    NLS 30835 | 4 Pole RCBO 16Amp 6kA | Type A

    The NLS 30835 is a sturdy 16-amp, 4-pole RCBO designed for dependable electrical protection. It combines overcurrent and residual current safety, reducing electrical hazards and meeting the latest AS/NZ 61009-1 standards. Its Type A classification detects sinusoidal AC residual currents for enhanced protection.

    NLS 30835 Features:

    • 6kA Breaking Capacity: Protects against overloads and short circuits.
    • Compact Build: Measures 84mm H x 71mm W x 80mm D, perfect for tight spaces.
    • User-Friendly Design: DIN rail mounting and lockable toggles simplify installation and use.
    • Earth Leakage Sensitivity: 30mA for accurate fault detection.
    • Versatile Voltage: Works with 240V and 415V systems.
    • Durable Terminals: Supports cables up to 25mm² for secure connections.

    NLS 30835 FAQ:

    Q: What is the RCBO’s breaking capacity?
    A: It offers a reliable 6kA breaking capacity, safeguarding against overcurrent issues.

    Q: Can it be used in three-phase systems?
    A: Yes, its 3P+N configuration protects three phases and neutral effectively.

    Q: Does it meet Australian standards?
    A: Absolutely, it complies with AS/NZ 61009-1 for safe, standard-compliant installations.

    (30835)

    Warranty

    Warranty starts from Invoice Date

    Domestic Use: 1 Year
    Commercial Use: 1 Year
    Warranty Method: Return to Sparky Direct

    Specifications

    These specifications and characteristics outline physical, mechanical, electrical details.

    Brand NATIONAL LIGHT SOURCES
    SKU 30835
    Barcode # 9336700016722
    Package Weight 0.426kg
    Package Width 0.075m
    Package Height 0.075m
    Package Length 0.085m
    TYPE VALUE
    Type Circuit Protection
    Brand National Light Sources
    Rated Current (A) 16
    Height (mm) 84
    Width (mm) 71
    Depth (mm) 80
    Standards AS/NZ 61009-1
    Mounting Din Rail
    Voltage (V) 240/415
    Number of Poles 3P+N
    IP Rating IP20
    Breaking Capacity 6kA
    Box increments (This item is sold individually) 1
    Earth Leakage Sensitivity 30mA
    Earth Leakage Protection Class Type A
    Curve C
