        HAGER NDN140A | Hager 40 Amp 10kA MCB Type D Single Pole
        $26.95 $24.50 ex. GST
        Description

        HAGER NDN140A | Hager 40 Amp 10kA MCB Type D Single Pole

        The Hager NDN140A is a D Curve single pole circuit breaker that protects and control circuits against overloads and short-circuits. The NDN140A circuit breaker is rated at 10kA and is suitable for commercial and industrial applications.

        Features:

        • 40 Amp
        • 1 Pole
        • 10kA
        • Curve D
        • Rated short circuit breaking capacity 10 kA
        • Frequency: 50/60 Hz
        • Rated insulation voltage: 500 V
        • Operating temperature: -25 to 60 °C
        • Electric endurance in number of cycles: 4000
        • Number of mechanical operations: 20000
        • Top and bottom screw terminals connection capacity with massive conductor: 1/35 mm²
        • Top and bottom screw terminals connection capacity with flexible cable: 1/25 mm²
        • Tightening torque: 2,8Nm
        • Height of installed product: 83 mm
        • Width of installed product: 17.5 mm
        • Depth of installed product: 70 mm

        (NDN140A)

        Warranty

        Warranty starts from Invoice Date

        Domestic Use: 1 Year
        Commercial Use: 1 Year
        Warranty Method: Return to Sparky Direct

        Specifications

        These specifications and characteristics outline physical, mechanical, electrical details.

        Brand Hager Electrical
        SKU NDN140A
        Barcode # 3250614618987
        Shipping Weight 0.3280kg
        Shipping Width 0.080m
        Shipping Height 0.050m
        Shipping Length 0.070m
        Shipping Cubic 0.000280000m3
