Clipsal by Schneider Electric | Solis T Series Wiser Push Button Adaptor | Platinum
The Clipsal 40PWSA-PT is a push button adaptor for the Clipsal Solis T Series, designed to accept a Wiser socket and present it as a push button control. The 40PWSA-PT is an aluminium component with a painted matt platinum finish, measuring 51mm high by 22mm wide by 30mm deep. It fixes with screws, mounts flush, installs horizontally, and carries RCM certification.
Push button control suits smart installations differently to a rocker or toggle, because a momentary press maps naturally to scenes and multi-function commands rather than a fixed on and off position. The push button control type determines that interaction at the wall, and the painted matt platinum finish governs how the plate reads against surrounding hardware.
Fixing method matters on a fit-out schedule, and this adaptor is a departure from the click-in components elsewhere in the range. The screw fixing mode takes a driver and a moment longer per position, but holds positively once set. Flush device mounting keeps the adaptor level with the plate face across a run of plates.
Features
- Push button control type — presents the Wiser socket as a momentary push button rather than a rocker or toggle action.
- Wiser socket carrier — the 40PWSA-PT is built to accept a Wiser socket and contains no switching mechanism itself.
- Screw fixing mode — fixes with screws rather than clipping in, so a driver is needed at install.
- Painted matt platinum finish — a matt surface finish with painted treatment in the platinum tint.
- Aluminium construction — the adaptor body is aluminium under the painted finish.
- Solis T Series range — part of the Clipsal Solis T Series, matching the range's plate system.
- Flush device mounting — finishes level with the plate face rather than standing proud.
- 51 x 22 x 30mm — 51mm high, 22mm wide, and 30mm deep.
- RCM certified — carries the Regulatory Compliance Mark for the Australian and New Zealand market.
- Single switch position — covers one position, so multi-gang plates need one adaptor per position.
- Horizontal installation only — the datasheet specifies horizontal installation direction for this adaptor.
- 0 to 45 degrees C ambient — a narrower operating range than many wall accessories, with 10 to 95 percent relative humidity.
Where to use
- Scene and multi-function control — the 40PWSA-PT gives Wiser a push button action suited to scenes rather than fixed on and off.
- Hotel and accommodation fit-out — guest rooms where push button control and a consistent plate finish are both specified.
- Residential smart lighting — homes running Wiser control across Solis T Series plates.
- Commercial reception and meeting spaces — front-of-house areas where the plate is part of the interior specification.
- Neutral and light interior schemes — the matt platinum tint suits pale joinery, grey palettes, and brushed metal hardware.
- Multi-gang smart plates — one adaptor per position where several Wiser sockets sit on a single plate.
The 40PWSA-PT is an adaptor only: it carries no switching mechanism and needs a Wiser socket and a Solis T Series plate to function. It fixes with screws rather than clipping in, so allow for a driver at install. Installation direction is horizontal, and the 0 to 45 degrees C operating range rules out unconditioned spaces that run hotter.
