The Major Tech ECC85 is a battery-powered hydraulic cable cutting tool developing 60kN of cutting force. It cuts cable to 85mm diameter through an 86mm stroke, covering copper, aluminium, armoured Cu/Al, and ACSR conductors. The ECC85 runs a two-stage hydraulic system with fast feed and power control, under micro-computer control. It is supplied in blue and black with 4.0Ah lithium batteries, a charger, and a carrying case.
Cutting 85mm cable by hand is not realistic work, and a ratchet cutter on armoured conductor is slow and inconsistent. The ECC85 develops 60kN through a two-stage hydraulic system, accelerating on approach before transferring to power control at the blade. Micro-computer control governs the cutting cycle rather than relying on operator judgement. An OLED display reports the tool's condition during operation.
The specification that determines suitability is the conductor type rather than the diameter alone. Major Tech lists the ECC85 for armoured Cu/Al cable, ACSR, and plain Cu/Al cable, encompassing most distribution and jointing applications. ACSR in particular defeats many cutters because of its steel core. The 86mm stroke gives the blade room to close fully on the largest conductors in range.
The ECC85 is a cable cutting tool only and carries no crimping function, dies, or crimping head. Cutting is rated to 85mm diameter, which is a ceiling rather than a guide, so larger conductors need a tool sized for them. A hydraulic tool at this rating develops substantial force at the blade, so keep hands clear and work to the manufacturer's instructions.
(ECC85)
Up to 85mm in diameter. The tool develops 60kN of cutting force through an 86mm stroke, which is what allows the blade to close fully on the largest conductors within range.
Major Tech lists armoured Cu/Al cable, ACSR, and plain copper or aluminium cable. ACSR is worth noting, since the steel core in overhead conductor defeats many conventional cutters.
The ECC85 is a cutter only, with no crimping head or dies. For crimping, Sparky Direct stocks the ECT240 and ECT400 crimpers, and the ECCT300 and ECCT450 combined crimper-cutters.
The ram runs fast feed on approach to close the blade quickly, then transfers to power control as it engages the conductor. That shortens cycle time without giving up force at the cut.
The cutting cycle is governed electronically rather than by operator judgement, which Major Tech lists as delivering consistency between cuts. The OLED display reports tool status during operation.
Lithium batteries, a charger, and a carrying case are supplied with the tool. Major Tech lists 4.0Ah lithium batteries on this model.
The ECC85 cuts to 85mm at 60kN and does nothing else. The ECCT450 cuts to 65mm plus 50mm armoured and also crimps to 400mm2, and the ECCT300 cuts to 30mm and crimps to 300mm2.
The Major Tech ECC85 is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 2 Year
Commercial Use: 2 Year
Warranty Method: Return to Sparky Direct
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Major Tech |
| SKU | ECC85 |
| Model # | ECC85 |
| TYPE | VALUE |
|---|---|
| Type | Crimping Tool |
| Brand | Major Tech |
| Colour | Blue & Black |
| Tool Type | Powered Tool |
| Batteries | 4.0Ah Lithium |
| Included | Lithium Batteries, Charger, Carrying Case |
| Cutting Range | 85mm |
| Cutting Force | 60kN |
