    Major Tech MT25 | 600V AC/DC IP67 Compact Multimeter

    Description:

    The MT25 600V AC/DC IP67 Compact multimeter is a handheld tester that provides fast and accurate measurements, displayed on a large 4000 count backlit display with the added advantage of a 41 segment analogue bargraph. The MT25 has a double moulded rubber housing with IP67 waterproof and dustproof rating for safety and durability and has the IEC 61010-1 CAT III 600V safety rating. Multiple measuring functions include AC and DC voltage, AC and DC current, resistance, capacitance, frequency, temperature and duty cycle, plus a continuity and diode test range. The MT25 also offers the added convenience of a built-in LED flashlight for dimly lit areas and a tilt stand.

    Features:

    • CAT III 600V and CAT II 1000V
    • IP67 Dust & Waterproof Double Moulded Housing
    • 41 Segment Bargraph
    • Measures AC and DC voltage up to 600V
    • Temperature measurement from -20°C to 760°C
    • 4000 count LCD display
    • Capacitance to 4000µF
    • 40MΩ Resistance
    • Backlit display to read easily in dimly lit areas
    • Min, Max & Data Hold
    • Auto Range and Manual Range Control
    • Duty Cycle
    • Diode Test & Continuity Test
    • LED Flashlight
    • Auto Power Off

    (MT25)

    Warranty

    Warranty starts from Invoice Date

    Domestic Use: 2 Year
    Commercial Use: 2 Year
    Warranty Method: Return to Sparky Direct

    All Major Tech Meters sold through Sparky Direct are covered by the manufacturer’s warranty. If you believe your meter is faulty or defective, you may request an assessment under this warranty policy.

    How to Lodge a Warranty Claim

    To initiate a warranty claim:

    1. Return to Sparky Direct
      Ship the meter back to Sparky Direct along with:

      • A copy of your proof of purchase
      • A brief description of the issue
      • Your contact details

      Please ensure the unit is securely packaged to prevent damage in transit.

    2. Forwarded for Assessment
      Upon receiving your meter, we will forward it to Major Tech’s authorised service centre for inspection, testing, and calibration.

    Assessment Process

    Major Tech’s service lab will assess the returned unit to determine:

    • Whether the fault is due to a manufacturer’s defect (covered under warranty), or
    • If the issue is the result of user error or no fault is found.

    Outcomes

    • If approved under warranty: The product will be repaired or replaced at no cost to you.
    • If not covered under warranty: The lab may offer repair services, which will be quoted and billed directly to you by the service provider.

    Important Notes

    As Major Tech’s service labs are independent providers, Sparky Direct cannot govern or guarantee turnaround times or any costs incurred for repairs outside of warranty coverage.

    Please allow up to 7-14 working days for the return of your product.

    Features

    Specifications

    Function Range Resolution Accuracy
    DC Voltage 400mV – 600V 1V ±(1.2% + 2 Digits)
    AC Voltage 4.000V – 600V 1V ±(1.5% + 10 Digits)
    DC Current 4A – 10A 10mA ±(3.0% + 5 Digits)
    AC Current 4A – 10A 10mA ±(3.0% + 5 Digits)
    Resistance 400Ω – 40MΩ 10kΩ ±(1.2% + 5 Digits)
    Capacitance 40nF – 4000mF 1µF ±(1.2% + 5 Digits)
    Frequency 9.999Hz – 9.999MHz 1kHz ±(1.2% + 3 Digits)
    Temperature -20°C – 760°C 1°C ±(3.0% + 5°C)
    Duty Cycle 0.1% – 99.9% 0.1% ±(1.2% + 2 Digits)
    Digital Display 4000 Count
    Continuity Test Audible signal if the resistance is approx. 50Ω or less
    Diode Test Test current 0.3mA typical, open circuit voltage 2.8V DC typical
    Data Hold Yes
    Back Light Yes
    Enclosure IP67 Dust & Waterproof Double Moulded
    Batteries 3 x AAA
    Dimensions 147 x 68 x 50mm
    Weight 318g
    Specifications

    These specifications and characteristics outline physical, mechanical, electrical details.

    Brand Major Tech
    SKU MT25
    Barcode # 6008229028878
    Package Weight 0.542kg
    Package Width 0.060m
    Package Height 0.180m
    Package Length 0.120m
    TYPE VALUE
    Type IP67 Compact Multimeter
    Brand Major Tech
    Height (mm) 50
    Width (mm) 68
    Length (mm) 147
