    Description

    Major Tech MT700 | 200A AC Clamp Meter

    Description:

    The MT700 is a CAT IV 600V, 2000 count True RMS 200A AC digital clamp meter with indication on a large backlit negative LCD display, with a clamp jaw opening of 16mm. A superb feature for electricians is the ability to simultaneously measure current and voltage and view both readings on the LCD display. The MT700 measures AC and DC voltage up to 1000V and displays the reading on both the LED and LCD display. This open jaw clamp meter is designed to assist in the ease of measuring current in crowded or tight cable areas, as the jaws need only be pushed over the wire to obtain accurate readings. Added features include resistance measurements, Rotary Field Indication, continuity buzzer, data hold, built-in flashlight plus Non-Contact Voltage detection. Housed in a modern double moulded rubber housing with a rugged design for heavy-duty use.

    Features:

    • CAT IV 600V and CAT III 1000V
    • 2000 count negative LCD display
    • Open Jaw Sensor
    • Ø16mm Cable Clamp size
    • Simultaneously displays voltage and current measurements
    • Measures DC voltage and AC voltage up to 1000V on LCD
    • LED indication of AC and DC voltage from 12V to 1000V
    • Resistance measurement to 2000Ω
    • Rotary Field Indication
    • NCV – Non-Contact Voltage Detector
    • Built-In Flashlight
    • Continuity buzzer and Data Hold function
    • Auto Power Off

    (MT700)

    Warranty

    Warranty starts from Invoice Date

    Domestic Use: 2 Year
    Commercial Use: 2 Year
    Warranty Method: Return to Sparky Direct

    All Major Tech Meters sold through Sparky Direct are covered by the manufacturer’s warranty. If you believe your meter is faulty or defective, you may request an assessment under this warranty policy.

    How to Lodge a Warranty Claim

    To initiate a warranty claim:

    1. Return to Sparky Direct
      Ship the meter back to Sparky Direct along with:

      • A copy of your proof of purchase
      • A brief description of the issue
      • Your contact details

      Please ensure the unit is securely packaged to prevent damage in transit.

    2. Forwarded for Assessment
      Upon receiving your meter, we will forward it to Major Tech’s authorised service centre for inspection, testing, and calibration.

    Assessment Process

    Major Tech’s service lab will assess the returned unit to determine:

    • Whether the fault is due to a manufacturer’s defect (covered under warranty), or
    • If the issue is the result of user error or no fault is found.

    Outcomes

    • If approved under warranty: The product will be repaired or replaced at no cost to you.
    • If not covered under warranty: The lab may offer repair services, which will be quoted and billed directly to you by the service provider.

    Important Notes

    As Major Tech’s service labs are independent providers, Sparky Direct cannot govern or guarantee turnaround times or any costs incurred for repairs outside of warranty coverage.

    Please allow up to 7-14 working days for the return of your product.

    Features

    Specifications



    Function Range Resolution Accuracy
    AC Current 0A – 200A 1A ±(3.5% + 5 Digits)
    DC Voltage 6V-1000V 1V ±(3.0% + 5 Digits)
    AC Voltage 6V-1000V 1V ±(3.0% + 5 Digits)
    Resistance 0Ω – 1999Ω 1Ω ±(5% + 10 Digits)
    AC Bandwidth 40Hz to 400Hz
    Digital Display 2000
    Non-Contact Voltage (NCV) Yes
    Overrange Indication Yes
    Continuity Yes
    Diode Test Yes
    Jaw Size 16mm Open Jaw
    Input Impedance >10MΩ DCV & >10MΩ VAC
    Data Hold Yes
    Back Light Yes
    Enclosure Double moulded case
    Low Battery Indication Yes
    Batteries 2 x AAA
    Weight 259g
    Dimensions 230 x 44 x 66mm
    Safety Specs IEC61010-1 CAT IV 600V
    Specifications

    These specifications and characteristics outline physical, mechanical, electrical details.

    Brand Major Tech
    SKU MT700
    Barcode # 6008229034428
    Package Weight 0.485kg
    Package Width 0.130m
    Package Height 0.060m
    Package Length 0.280m
    TYPE VALUE
    Type Clamp Meter
    Brand Major Tech
    Dimensions 230 x 44 x 66mm
    Batteries 2 x AAA
