Learn more by watching our Major Tech MT936 | Non-Contact Phase Rotation Meter video.
The Major Tech MT936 is a non-contact phase rotation meter that determines 3-phase sequence over insulated conductors, rated 70V to 1000V AC. The MT936 clamps onto conductors up to 30mm without exposing live parts, and is built to IEC 61010-1 at CAT IV 600V and CAT III 1000V. It uses colour LED indication and an audible buzzer to confirm clockwise or anti-clockwise rotation.
Getting phase sequence wrong on a 3-phase connection drives motors, pumps, and compressors in reverse, risking mechanical damage at startup. Contact phase testers require exposed terminals, which means working adjacent to live conductors to obtain a reading. The MT936 determines phase rotation across the conductor insulation, so there is no need to expose the cores. Its clamp opens to 30mm, accommodating most sub-mains and feeder cables at the switchboard.
Licensed electricians reach for the MT936 to confirm rotation before energising motor circuits or commissioning three-phase equipment. The built-in magnet holds the unit on a distribution board or metal enclosure, freeing both hands to position the clamps. Green and red LEDs plus a buzzer give an immediate call on direction, and a brightness button lifts LED visibility in full sun. For commissioning and fault-finding work, it keeps phase checks quick and non-invasive.
The MT936 carries an IP40 rating, so it is not sealed against water and should not be used in wet, damp, or submerged conditions. It reads phase rotation only and does not measure voltage, insulation resistance, or continuity. Keep readings within the rated 70 to 1000V AC range and within the CAT IV 600V or CAT III 1000V limits.
(MT936)
It is used to check the phase rotation of 3-phase systems before connecting equipment like motors.
It ensures motors and equipment run in the correct direction and avoids damage on startup.
It works without touching conductors, making it safer and quicker to use.
No. It clamps over insulated conductors, so no exposure is needed.
The MT936 runs on a single 9V battery. A low-battery warning flashes the power LED at about 7.2V and shuts the unit off near 6.2V to protect the reading. Auto power-off cuts in after roughly 10 minutes idle to preserve battery life.
The Major Tech MT936 is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 2 Year
Commercial Use: 2 Year
Warranty Method: Return to Sparky Direct
All Major Tech Meters sold through Sparky Direct are covered by the manufacturer’s warranty. If you believe your meter is faulty or defective, you may request an assessment under this warranty policy.
To initiate a warranty claim:
Return to Sparky Direct
Ship the meter back to Sparky Direct along with:
Please ensure the unit is securely packaged to prevent damage in transit.
Forwarded for Assessment
Upon receiving your meter, we will forward it to Major Tech’s authorised service centre for inspection, testing, and calibration.
Major Tech’s service lab will assess the returned unit to determine:
As Major Tech’s service labs are independent providers, Sparky Direct cannot govern or guarantee turnaround times or any costs incurred for repairs outside of warranty coverage.
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Major Tech |
| SKU | MT936 |
| Model # | MT936 |
| Barcode # | 6008229040498 |
| Package Weight | 0.499kg |
| TYPE | VALUE |
|---|---|
| Type | Phase Rotation Meter |
| Brand | Major Tech |
| Power Source | 1 x 9V battery |
| Voltage (V) | 70 to 1000 (3-phase AC) |
| IP Rating | IP40 |
| Dimensions | 135 x 75 x 31mm |
