Name: Major Tech PIR36 | 360° Indoor PIR Motion Sensor Surface Mount | IP20
Brand: Major Tech
SKU: PIR36
Price: 25.30 AUD
Availability: InStock

Major Tech PIR36 | 360° Indoor PIR Motion Sensor Surface Mount | IP20

The Major Tech PIR36 is a 360° ceiling-mounted PIR motion sensor built for indoor automation of lighting or devices based on movement and body heat. With up to 8 metres detection range, it helps reduce power usage by only activating lights when needed, making it perfect for homes, hallways, offices, and storage areas.

Designed for surface mounting, it features adjustable lux sensitivity and timer settings, allowing users to customise operation based on ambient light and time delay. With support for high load ratings and low standby power, it’s efficient, compact, and easy to integrate into new or existing installations.

PIR36 Features

360° Detection Coverage: Full room sensing up to 8m radius

Adjustable Lux & Timer: Set lux from <3–2000 and delay from 10s–15min

High Load Capacity: 2000W incandescent or 1000W LED/CFL

Low Power Standby: <0.5W consumption

Indoor Surface Mount: IP20 housing for dry environments

Standards Approved: IEC 60669-1 / 60669-2-1, AS/NZS 60669.1 / 60669.2.1

PIR36 FAQ

Q: Can this be installed outdoors?
A: No, it's IP20 rated and must be installed indoors only.

Q: What types of spaces is this suited to?
A: Ideal for homes, offices, hallways, and enclosed storage areas.

Q: Does it require a neutral wire?
A: Yes, it must be installed by a qualified electrician with a neutral connection.

Specification

Details

Function

360°

Detection Distance

2m – 16m (Adjustable) <24°C

Detection Motion Speed

0.6 to 1.5 m/s

HF System

5.8GHz CW Radar, ISM Band

Ambient Light

<3 to 2000 Lux (Adjustable)

Installation Height

1.5m – 3.5m

Voltage

220 to 240V AC

Power Frequency

50/60Hz

Rated Load

Incandescent: 1200W
LED / CFL: 300W

Time Delay

10 sec (±3 sec) to 12 min (±1 min)

Power Consumption

<0.9W

Mounting

Ceiling Mount

Working Temperature

-20°C to 40°C

Working Humidity

<93% RH

IP Rating

IP20 (Indoor installation)

Standards

IEC 60669-1 / 60669-2-1
AS/NZS 60669.1 / 60669.2.1

TYPE

VALUE

Type

Sensor

Brand

Major Tech

Voltage (V)

220 to 240V AC

IP Rating

IP20

Time Delay

10 sec (±3 sec) to 15 min (±2 min)

Cut Out ø

Ø64mm

Detection Distance

6M Max

Installation Height

2.2m - 4m

Detection Area

360°

Detection Motion Speed

0.6 to 1.5m/s

Ambient Light

<3 to 2000 Lux (Adjustable)

Brand	Major Tech
SKU	PIR36
Model #	PIR36
Barcode #	6008229007118
Package Weight	0.145kg
Package Width	0.038m
Package Height	0.155m
Package Length	0.120m
