        NLS 30837 | 10A RCBO Single Pole 6KA Atype / Tails

        The NLS 30837 10A RCBO Single Pole provides reliable circuit protection with a 6KA short circuit capacity and A-Type tripping for sensitive applications. Designed for single-phase systems, it ensures efficient fault detection, including residual and overload currents.

        Pre-wired tails simplify the installation process, saving time and effort. Its compact form factor is ideal for modern electrical distribution boards, making it a practical choice for safety compliance.

        NLS 30837 Features

        • Rated Current: 10A - Suitable for low to medium electrical loads.
        • Tripping Curve: A-Type - Offers protection against AC and pulsating DC residual currents.
        • Breaking Capacity: 6KA - High performance for short-circuit fault management.
        • Pre-Wired Tails - Simplifies connections during installation.
        • Compact Design - Fits seamlessly in standard distribution boards.

        NLS 30837 FAQ

        Q: What type of applications is this RCBO suitable for?
        A: It is suitable for residential and light commercial electrical installations.

        Q: Does this RCBO support dual-function protection?
        A: Yes, it protects against both residual currents and overloads.

        Q: Are the pre-wired tails a standard feature?
        A: Yes, the pre-wired tails come standard to ensure easy and quick installation.

        (30837)

        Warranty

        Warranty starts from Invoice Date

        Domestic Use: 2 Year
        Commercial Use: 2 Year
        Warranty Method: Return to Sparky Direct

        Specifications

        These specifications and characteristics outline physical, mechanical, electrical details.

        Brand NATIONAL LIGHT SOURCES
        SKU 30837
        Barcode # 9336700016661
        Package Weight 0.164kg
        Package Width 0.076m
        Package Height 0.030m
        Package Length 0.107m
        TYPE VALUE
        Type Circuit Protection
        Brand National Light Sources
        Rated Current (A) 10
        Height (mm) 92
        Width (mm) 18
        Depth (mm) 77
        Standards AS/NZ 61009-1
        Mounting Din Rail
        Curve C
        Voltage (V) 240V
        Earth Leakage Protection Class Type A
        Earth Leakage Sensitivity 30mA
        Residual Current 30mA
        Breaking Capacity 6kA
        Overcurrent trip characteristic C Curve
        Earth Fault Wave Form Type A
        IP Rating IP20 ( IP40 Enclosed )
        Number of Poles 1P+N
