The Wago 2202-1201 is a two-conductor through terminal block rated 24A at 800V. This listing supplies one block rather than Wago's hundred-piece pack. The 2202-1201 takes 0.25 to 4mm2 copper conductors and mounts on DIN-35 rail at 5.2mm wide. Conductors go in through a push-button Push-in CAGE CLAMP, and there is a 2mm test port in the front face.
Panel terminal counts rarely land on a round number. Supplied as a single block, the 2202-1201 lets a rail be filled to the exact number of ways a job needs. At 5.2mm wide each block takes very little rail, so another way can often be added without shifting gear along. The 0.25 to 4mm2 range covers fine signal wiring through to a 4mm2 feed on one part number.
Checking a circuit usually means undoing something first. The 2mm test port takes a test plug, so a reading comes off the block with the wiring left alone. Push-button actuation holds spring pressure on the conductor instead of relying on a screw staying torqued. Two jumper slots take a push-in jumper bar, so a set of ways is commoned in one go.
The 24A figure is the IEC/EN rating, not the number to work to everywhere. Under UL 1059 and CSA the block is 20A at 600V, and in Ex e II applications it is 22A, or 20A with a jumper fitted. The test plug is rated to 42 V, so the port is a test point, not somewhere to probe at working potential.
(2202-1201-Single)
One block. Wago packs this item in boxes of one hundred, and this listing breaks the pack so a rail can be filled to the exact number of ways it needs.
24A at 800V under IEC/EN 60947-7-1, with an 8kV rated surge voltage. Under UL 1059 and CSA 22.2 No 158 the rating is 20A at 600V, so check which standard the job is being built to.
0.25 to 4mm2 solid or fine-stranded copper, which is 22 to 12 AWG. The 2.5mm2 figure in the product name is the nominal cross-section, not the largest conductor the block accepts.
Solid conductors from 0.75 to 4mm2 and ferruled ones from 1 to 2.5mm2 push straight in. Bare fine-stranded conductors need the operating tool, and so does getting any conductor back out.
It takes a 2mm test plug, rated to a maximum of 42 V. Drop the plug in and take the reading with the conductors still terminated, so nothing has to be undone to check the circuit.
Wago lists the block as suitable for Ex e II applications, with ATEX, IECEx, AEx, CCCEx and EAC approvals covering Ex eb IIC Gb. The Ex e II rating is 550V and 22A, dropping to 20A with a jumper fitted.
5.2mm of rail per block. It stands 48.5mm high and 39.5mm deep, sitting 32.9mm off the top edge of the rail, and weighs 5.3g.
Yes. Wago lists an end and intermediate plate as a required accessory, sold separately. Allow one for the end of each terminal run.
The Wago 2202-1201 is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 1 Year
Commercial Use: 1 Year
Warranty Method: Return to Sparky Direct
| Specification | Details |
|---|---|
| Item Number | 2202-1201 |
| Connection Technology | Push-in CAGE CLAMP® |
| Rated Voltage | 800 V |
| Rated Surge Voltage | 8 kV |
| Rated Current | 24 A |
| Dimensions (WxHxD) | 5.2 x 48.5 x 39.5 mm |
| Operating Temperature | -60°C to +105°C |
| Material | Polyamide (PA66) |
| Flammability Class | UL94 V0 |
| Weight | 5.3 g |
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Wago |
| SKU | 2202-1201-Single |
| Model # | Wago 2202-1201-Single |
| Barcode # | 4055143848497 |
| Package Weight | 0.005kg |
| TYPE | VALUE |
|---|---|
| Type | Electrical Accessories |
| Brand | Wago |
| Height (mm) | 48.5 |
| Width (mm) | 5.2 |
| Depth (mm) | 39.5 |
| Nominal Voltage | 800V |
| Weight (g) | 5 |
| Rated Current | 24A |
| Connection points | 2 |
| Rated Surge Voltage | 8kV |
