Clipsal by Schneider Electric | Iconic Zigbee Connected Switch 2AX 240V | Vivid White
The Clipsal Iconic 41E2PBSWMZ-VW is a Zigbee-connected switch mechanism rated 2AX at 240V, designed for smart home lighting and exhaust fan control. The 41E2PBSWMZ-VW integrates with the Wiser Hub for remote control via app or voice command, while retaining the tactile push-button option at the wall. It complies with AS/NZS 60669.2.1 and supports both Zigbee (default) and Bluetooth Low Energy protocols.
Installers and home builders often need to add remote control or automation to existing lighting circuits without rewiring. Modern renovations and smart homes demand both local tactile switches and app-based automation from a single device. The Iconic 41E2PBSWMZ-VW fits off quickly into standard 16mm or 20mm wall boxes, so electricians can retrofit or new-build without design constraints.
Licensed electricians value the 41E2PBSWMZ-VW for its easy setup and integration into existing home automation systems. The Wiser app configures timers and schedulers in minutes, and because it works with third-party hubs (Amazon Alexa, Home Assistant), it suits customer installations without vendor lock-in. The 2AX load rating handles LED drivers, electronic transformers, and halogen loads, making it ideal for modern retrofit and new-build lighting across residential and renovation work.
Features
- Zigbee and Bluetooth LE support — default Zigbee mode connects to the Wiser Hub; Bluetooth LE operates standalone without a hub.
- 2AX rated load — handles LED lighting drivers, dimmable and non-dimmable, electronic transformers, and medium voltage halogen loads up to 2 amps per circuit.
- Tactile push-button plus app control — wall-mounted Vivid White button provides manual on/off; the Wiser by SE app adds remote, timer, and voice command options.
- Wiser app configuration — set time delays from 1 second to 24 hours, LED indicator behaviour, and device naming directly from mobile.
- Iconic range compatibility — uses the same 84mm plate centres and backing mechanism as all Clipsal Iconic switches, so electricians can stock one base and swap mechanisms for different jobs.
- Three-wire installation — requires neutral, active, and load connections; 40mm minimum wall box depth.
- Over-temperature and thermal protection — built-in safeguards prevent overload damage if LED or transformer specs exceed device ratings.
- AS/NZS 60669.2.1 compliant — safety and EMC certified for Australian and New Zealand electrical installations, with no approval restrictions on domestic or commercial use.
- IP20 rated, indoor use only — suitable for internal walls only; not weatherproof or rated for external, damp, or splash zones.
- One-year domestic and commercial warranty — Clipsal in-home warranty covers manufacturing defects from invoice date.
Where to use
- Smart lighting circuits — the 41E2PBSWMZ-VW is ideal for living areas and bedrooms where occupants want both manual wall control and smartphone or voice command.
- Home automation retrofits — fits into existing wall boxes without replumbing or rerouting; perfect for adding smart control to older homes during renovation.
- Exhaust fan automation — 2AX load suits bathroom and kitchen extraction fans, with app-based timer scheduling to reduce humidity and odours.
- Multi-gang light controls — the Clipsal Iconic 41E2PBSWMZ-VW works alongside manual switches and other Iconic Wiser mechanisms on the same 84mm plates up to 6 gangs per plate.
- Alexa and Home Assistant integration — pairs directly with Amazon Echo Hub or works through Zigbee bridges in Home Assistant for centralised home control.
- Residential and small commercial — suitable for houses, units, holiday rentals, and light commercial installations where smart scheduling improves energy efficiency.
The Clipsal Iconic 41E2PBSWMZ-VW is not suitable for external walls, damp exposed locations, or splash zones in bathrooms and kitchens. It is rated IP20 for indoor use only and should not be installed in areas subject to water ingress or high humidity without protection. Do not install where the load exceeds 2AX or where sustained heat (e.g., appliance proximity) would exceed 25°C operating temperature.
