The Clipsal 755RB5 is a smoke alarm mounting base with an integrated relay, rated 220-240 V a.c. 50 Hz, and forms part of the Clipsal Fire Tek range. The 755RB5 carries voltage-free NO, COM and NC relay contacts, rated 250 V a.c. 2 A, for switching a connected auxiliary device. It is manufactured to AS/NZS 3100 and rated IP20 for indoor installation.
Where an alarm activation has to switch an auxiliary device and not just sound, that switching comes from the base rather than the alarm. The 755RB5 provides voltage-free NO, COM and NC contacts that operate when the fitted alarm is triggered. The relay works on mains supply or on the alarm backup battery. Its terminals sit under their own cover, segregated from the mains terminals by a physical barrier.
Fitting follows the same steps as a plain mounting base. Active, neutral and interconnect land on the base terminals, the cover clips shut, and the alarm latches on at the hinge. Relay behaviour is set at the alarm itself with a Global or Local switch that works with this base only. Separate T, H and C terminals take a remote test or hush button wired away from the alarm.
The 755RB5 is not rated for damp locations, is not suitable for outdoor installation, and must not be attached to freshly painted or electrically conductive surfaces such as metal. It must not be connected to a circuit carrying inductive loads, and it will not work with third-party systems such as fire panels. There are no user-serviceable parts inside the base.
(755RB5)
The 755RB5 is a smoke alarm mounting base with an integrated relay, from the Clipsal Fire Tek range. A compatible Clipsal smoke alarm latches onto the base. The base adds voltage-free relay contacts that switch an external device when the alarm triggers, plus terminals for a remote test or hush button.
The 755RB5 is built to AS/NZS 3100 and complies with AS/NZS 60065 and AS/NZS 60950.1. It carries ActivFire certification and the Regulatory Compliance Mark. The base must be installed in line with the National Construction Code and any local state legislation.
No. The smoke alarm base must be installed by a licensed electrician. The electrical supply is isolated first, then active, neutral and interconnect wires are landed on the base terminals and the screws fully tightened. The terminal cover clips closed before the base is screwed to the ceiling.
The base takes the Clipsal 755RLPSMA2, 755RLPSMA4, 755PSMA2, 755PSMA4, 755WSA, 755PSMA5 and 755PSMA5L smoke alarms, and the 755HA5L heat alarm. It is not compatible with third-party products or systems such as fire panels.
The relay provides voltage-free NO, COM and NC contacts rated 250 V a.c. 2 A for external devices such as a strobe, siren, light or building management system. Each relay terminal takes one 2.5 mm2 cable. The relay terminals are segregated from the mains supply terminals by a physical barrier, and the relay operates on mains or backup battery power.
The base is rated IP20 and is for indoor installation only. Keep the terminal connection area clear of the metallic parts of any other device in the same location. Do not supply it from a non-pure sinusoidal source such as a square-wave inverter. Do not modify it after installation.
Schneider Electric warrants the base free from defects in materials and workmanship for five years from the date of installation, covering both domestic and commercial use. Clipsal handles claims directly under its in home warranty. Warranty is void if the product is not installed by a licensed electrician.
The Clipsal by Schneider Electric 755RB5 is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 5 Years
Commercial Use: 5 Years
Warranty Method: Clipsal in home warranty
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Clipsal by Schneider Electric |
| SKU | 755RB5 |
| Model # | 755RB5 |
| Barcode # | 3606487696414 |
| Package Weight | 0.182kg |
| TYPE | VALUE |
|---|---|
| Type | Smoke Alarm Relay Base |
| Brand | Clipsal by Schneider Electric |
| Range | Fire Tek |
| Colour | White |
| Depth (mm) | 30 |
| Voltage (V) | 220-240 |
| Diameter (mm) | 140 |
| IP Rating | IP20 |
