The Wago 2204-1201 is a two-conductor through terminal block rated 32A at 800V. This listing supplies one block rather than Wago's fifty-piece pack. The 2204-1201 takes 0.5 to 6mm2 copper conductors and mounts on DIN-35 rail at 6.2mm wide. Conductors go in through a push-button Push-in CAGE CLAMP, and there is a 2mm test port in the front face.
Panel terminal counts rarely land on a round number. Supplied as a single block, the 2204-1201 lets a rail be filled to the exact number of ways a job needs. At 6.2mm wide each block takes very little rail, so another way can often be added without shifting gear along. The 0.5 to 6mm2 range covers signal wiring through to a 6mm2 feed on one part number.
Checking a circuit usually means undoing something first. The 2mm test port takes a test plug, so a reading comes off the block with the wiring left alone. Push-button actuation holds spring pressure on the conductor instead of relying on a screw staying torqued. Two jumper slots take a push-in jumper bar, so a set of ways is commoned in one go.
The 32A figure is the IEC/EN rating, not the number to work to everywhere. Under UL 1059 and CSA the block is 30A at 600V, and in Ex e applications it is 31A, or 30A with a jumper fitted. The test plug is rated to 42 V, so the port is a test point, not somewhere to probe at working potential.
(2204-1201-Single)
One block. Wago packs this item in boxes of fifty, and this listing breaks the pack so a rail can be filled to the exact number of ways it needs.
32A at 800V under IEC/EN 60947-7-1, with an 8kV rated surge voltage. Under UL 1059 and CSA 22.2 No 158 the rating is 30A at 600V, so check which standard the job is being built to.
0.5 to 6mm2 solid or fine-stranded copper, which is 20 to 10 AWG. The 4mm2 figure in the product name is the nominal cross-section, not the largest conductor the block accepts.
Solid conductors from 1 to 6mm2 and ferruled ones from 1.5 to 4mm2 push straight in. Bare fine-stranded conductors need the operating tool, and so does getting any conductor back out.
It takes a 2mm test plug, rated to a maximum of 42 V. Drop the plug in and take the reading with the conductors still terminated, so nothing has to be undone to check the circuit.
6.2mm of rail per block. It stands 52.3mm high and 39.5mm deep, sitting 32.9mm off the top edge of the rail, and weighs 7.1g.
Yes. Each block has two jumper slots. Drop a push-in jumper bar in and press it down until it hits the backstop. A step-down jumper is also available for commoning across to smaller blocks in the range.
Yes. Wago lists an end and intermediate plate as a required accessory, sold separately. Allow one for the end of each terminal run.
The Wago 2204-1201 is available online from Sparky Direct, with Australia-wide delivery to any state or territory including regional areas. Sparky Direct is an Australian electrical wholesaler established in 2005, supplying more than 500,000 customers with transparent trade pricing.
100-Day Fuss-Free Returns
We want you to love what you buy—but if you change your mind, that’s okay too. That’s why Sparky Direct offers a 100-day money-back guarantee.
If your item isn’t in its original condition, please contact us before returning it—we might save you time and money.
All products come with a manufacturer’s or supplier’s warranty
Damaged or Faulty Goods
If your order arrives damaged or is faulty, let us know within 24 hours.
Contact us via our chat to arrange the return.
Exclusions
We can’t accept returns for:
How to Request a Return
Warranty starts from Invoice Date
Domestic Use: 1 Year
Commercial Use: 1 Year
Warranty Method: Return to Sparky Direct
| Specification | Details |
|---|---|
| Item Number | 2204-1201 |
| Connection Technology | Push-in CAGE CLAMP® |
| Rated Voltage | 800 V |
| Rated Surge Voltage | 8 kV |
| Rated Current | 32 A |
| Dimensions (WxHxD) | 6.2 x 52.3 x 39.5 mm |
| Operating Temperature | -60°C to +105°C |
| Material | Polyamide (PA66) |
| Flammability Class | UL94 V0 |
| Weight | 7.1 g |
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | Wago |
| SKU | 2204-1201-Single |
| Model # | 2204-1201 |
| Barcode # | 4055143847087 |
| Package Weight | 0.007kg |
| TYPE | VALUE |
|---|---|
| Type | Electrical Accessories |
| Brand | Wago |
| Height (mm) | 52.3 |
| Width (mm) | 6.2 |
| Depth (mm) | 39.5 |
| Nominal Voltage | 800V |
| Weight (g) | 7 |
| Rated Current | 32A |
| Connection points | 2 |
| Rated Surge Voltage | 8kV |
